ROTARY BLISTER PACKING MACHINE
ROTOMAX 150
High-Speed Single Track Rotary Blister Packaging Machine
The ROTO MAX-150 Automatic Rotary Blister Packing Machine by Maxen Pharma Machine is a high-speed, fully automatic blister packaging solution designed for packaging tablets, capsules. Engineered with advanced rotary technology, the machine is compatible with PVC-ALU blister packaging and delivers consistent forming, sealing, and cutting for medium to high-volume pharmaceutical production.Manufactured using SS 304 stainless steel cladding and designed according to GMP standards, the ROTO MAX-150 provides hygienic operation, reduced maintenance, and easy cleaning.
Applications
The ROTOMAX-150 is suitable for packaging
- Tablets
- Capsules
- Nutraceutical Products
- Healthcare Products
- Pharmaceutical Products
Compatible Packaging Materials
The machine supports:
- Transparent PVC Film
- Opaque PVC Film
- PVC/PVDC Film
- PVC with Paper Coating
- Aluminium Lidding Foil
It also supports:
- Online Batch Coding
- Perforation Between Blister Pockets
- High Quality Pvc-Alu heat Forming Packaging
Key Features
Fully Automatic Operation
The machine performs automatic forming, feeding, sealing, batch coding, perforation, and cutting operations for continuous production.
High-Speed Rotary Technology
Rotary indexing enables smooth and continuous blister production with significantly higher output than conventional intermittent machines.
GMP-Compliant Construction
Designed in accordance with pharmaceutical manufacturing requirements with smooth surfaces for easy cleaning and hygiene.
SS 304 Stainless Steel Cladding
Complete stainless-steel body offers excellent corrosion resistance, durability, and long operational life.
Contact Heating System
Ensures uniform sealing temperature for consistent blister sealing and improved packaging quality.
No Compressed Air Requirement
Unlike conventional blister machines, the ROTO MAX-150 operates without compressed air, reducing operating costs and simplifying installation.
Compact & Heavy-Duty Design
Optimized machine layout saves valuable production floor space while maintaining structural rigidity.
Quick Format Changeover
Reduced changeover time improves production flexibility and minimizes machine downtime.
Technical Specifications :
| Specification | Details |
|---|---|
| Model | ROTO MAX-150 |
| Machine Dimensions | 1600 mm (L) + 700 mm Conveyor × 850 mm (W) × 1750 mm (H) |
| Net Weight | Approx. 900 kg |
| Production Speed | Up to 120 Packs/Minute* |
| Power Consumption | 4.5 kVA (Without Air Compressor) |
| PVC Base Film Width | Maximum 124 mm |
| PVC Film Thickness | 0.25 mm |
| PVC Reel Diameter | Maximum 440 mm |
| Aluminium Foil Width | 120 mm |
| Aluminium Foil Thickness | 0.02 / 0.03 mm |
| Aluminium Foil Reel Diameter | 220 mm |
| Advance Length | 100 mm |
| Maximum Forming Depth | 10 mm |
| Forming Area | Min. 25 × 110 mm / Max. 100 × 110 mm |
| Maximum Pack Length | 110 mm |
| Maximum Pack Width | 100 mm |
| Control Panel | User-Friendly Control Panel |
Benefits:
High Production Capacity
Capable of producing up to 120 blister packs per minute, making it ideal for medium to large-scale pharmaceutical production.
Lower Operating Costs
No compressed air requirement and efficient electrical operation help reduce utility expenses.
Reliable Packaging Quality
Precision rotary forming and contact heating provide consistent blister formation and secure sealing.
GMP-Friendly Manufacturing
Hygienic stainless-steel construction supports pharmaceutical compliance and easy maintenance.
Increased Productivity
Fast format changeovers and automatic operation minimize downtime and maximize production output.
Long Machine Life
Heavy-duty industrial construction ensures reliable performance under continuous manufacturing conditions.
Utility Requirements
| Requirement | Specification |
|---|---|
| Electrical Supply | 415V, 3 Phase, 50Hz, 25 AMP |
| Air Requirement | 7 Kg/cm² @ 15 CFM |
| Cooling Water | 15–20°C, 40 LPM |
Industries Served
- Pharmaceutical Industry
- Nutraceutical Industry
- Healthcare Industry
- Herbal Products
- Food Supplement Manufacturing
Frequently Asked Questions
The ROTO MAX-150 is designed for manufacturers looking to achieve high-speed blister packaging with exceptional reliability and low operating costs. Its rotary mechanism, GMP-compliant design, stainless-steel construction, and energy-efficient operation make it a dependable solution for pharmaceutical and medical packaging applications.
Yes. The machine features a GMP-compliant stainless-steel design suitable for pharmaceutical manufacturing.
Capable of producing up to 200 blister packs per minute, making it ideal for medium to large-scale pharmaceutical production.
Yes. It includes an online batch coding system with a print area of 200 × 110 mm.
